Maitrik PTFE Lining produces high-quality PTFE Lined Reducers designed to perform optimally in demanding industrial applications. Operating from Jakarta, Indonesia, we are a reliable manufacturer and supplier of PTFE, FEP, and PFA lined products for their reliability and durability. Our PTFE Lined Reducers are particularly designed to endure harsh chemicals and high temperature while providing steady long-term performance and operational effectiveness. With excellent chemical resistance, sturdy construction, and a smooth inner surface, these reducers allow smooth flow transition among different pipe sizes. Being configurable in forms, they can be configured to meet diverse process demands and industry norms.
A PTFE-lined reducer is a specialty pipe fitting to join two pipes of varying diameters with a high degree of chemical resistance and efficiency of flow. It has an internal lining of Polytetrafluoroethylene (PTFE)—a non-reactive, corrosion-resistant material—and is thus well-suited for applications in industries that deal with aggressive chemicals, acids, or high-purity chemicals.PTFE-lined reducers find general application in chemical processing, pharmaceuticals, food and beverages, and water treatment facilities. The PTFE lining insulates the process fluid from coming into contact with anything other than the inert surface, minimizing contamination and extending equipment life. There are two broad types of PTFE-lined reducers: concentric, whose centerlines coincide, and eccentric, where they don’t—both specifically designed for particular flow applications. They play a crucial function overall in sustaining system integrity, enhancing flow transition, and ensuring safe and efficient operation within hostile industrial processes.
Size : 25 NB to 300 NB
Outer body : ASTM A 395 Gr 60-40-18
Flange Connection : ANSI B 16.5
Face to Face : ANSI B 16.10
Spark Test : 15 KVA
Hydro Test : at 29.8 kg/cm2
FEP- Max Temp : 180° C
PP Max Temp : 100° C
PFA Max Temp : 200° C
Maitrik PTFE Lining is a leading supplier of PTFE Lined Reducer in Jakarta, Indonesia, offering high-quality, corrosion-resistant solutions ideal for chemical, pharmaceutical, and industrial applications.
| NB | L | FLG. | RF | PCD | App. | App. | LINER THK | N x M | WEIGHTS | |
|---|---|---|---|---|---|---|---|---|---|---|
| O / D | O / D | T1 | T1 | Vaccume (T) | Non Vacc (T) | (kg/piece) | ||||
| 1/2″ | —- | 89 | 35.1 | 60.5 | 14.2 | 24.2 | 3.0 | 3.0 | 4 x 1/2″ | 4 |
| 3/4″ | —- | 98 | 42.9 | 69.9 | 15.7 | 27.7 | 3.0 | 3.0 | 4 x 1/2″ | 3.5 |
| 1″ | 89 | 108 | 50.8 | 79.2 | 17.2 | 29.2 | 4.0 | 3.0 | 4 x 1/2″ | 5.5 |
| 1 1/4″ | 95 | 118 | 63.5 | 88.9 | 18.7 | 30.2 | 4.0 | 3.0 | 4 x 1/2″ | 7.7 |
| 1 1/2″ | 102 | 127 | 73.2 | 98.6 | 20.5 | 32.5 | 4.0 | 3.0 | 4 x 1/2″ | 8.7 |
| 2″ | 114 | 152 | 91.9 | 120.7 | 22.1 | 37.1 | 4.0 | 3.0 | 4 x 1/2″ | 14.0 |
| 2 1/2″ | 127 | 178 | 104.6 | 139.7 | 25.4 | 40.4 | 4.0 | 3.0 | 4 x 5/8″ | 20.6 |
| 3″ | 140 | 191 | 127.0 | 152.4 | 27.9 | 42.9 | 4.0 | 3.0 | 4 x 5/8″ | 24.8 |
| 4″ | 165 | 229 | 157.2 | 190.5 | 28.9 | 43.9 | 4.5 | 3.0 | 8 x 5/8″ | 39.1 |
| 5″ | 190 | 254 | 185.7 | 215.9 | 28.9 | 43.9 | 6.0 | 5.0 | 8 x 3/4″ | 68.8 |
| 6″ | 203 | 279 | 215.9 | 241.3 | 30.4 | 45.4 | 6.0 | 5.0 | 8 x 3/4″ | 79.5 |
| 8″ | 229 | 343 | 269.7 | 298.5 | 33.4 | 48.4 | 6.0 | 5.0 | 8 x 3/4″ | 99.0 |
| 10″ | 280 | 406 | 323.9 | 362.0 | 35.7 | 50.7 | 7.5 | 5.0 | 12 x 7/8″ | 160.0 |
| 12″ | 305 | 483 | 381.0 | 431.8 | 37.8 | 52.8 | 7.5 | 5.0 | 12 x 7/8″ | 280.0 |
Withstands harsh acids and solvents.
Prevents fluid leakage at joints.
Suitable for extreme process heat.
Tailored to fit system specifications.
It connects pipes of different diameters while providing excellent corrosion resistance in aggressive chemical environments.
All offer chemical resistance, but PTFE is widely used for general applications, FEP allows for easier processing, and PFA offers higher temperature resistance and flexibility.
Yes, Maitrik PTFE Lining offers customizable configurations to meet specific process and piping requirements.
They’re used in chemical processing, pharmaceuticals, food & beverage, water treatment, and other corrosive service applications.
We offer both concentric (center-aligned) and eccentric (offset) reducers for different flow and installation needs.
