Maitrik PTFE Lining is a key player in the manufacturing industry, producing high-quality Teflon Lined Fittings that are perfect for critical industrial processes involving corrosive and high-temperature media. Based in Jakarta, Indonesia, we are a trusted supplier of FEP, PFA, and PTFE lined components. Our Teflon Lined Fittings are built to be durable, resistant to chemicals and maintain reliable performance in demanding applications. With a smooth interior lining, strong construction, and excellent sealing efficiency these fittings ensure effective fluid handling and can be customized to meet specific system needs and process requirements.
Teflon Lined Fittings are industrial pipe fittings with an internal Teflon (PTFE) coating, a high-performance, non-reactive fluoropolymer. The fittings can be used to handle aggressive chemicals, corrosives, and high-temperature fluids safely without degrading. The Teflon coating provides the surface a non-stick, smooth finish that leads to leak-tight performance, reduces contamination, and extends the piping system’s lifespan. Extensively used in the pharmaceutical, chemical processing, water treatment, food and beverage processing, and allied industries, Teflon Lined Fittings help to ensure purity, efficiency of flow, and safety of environments during aggressive processing.
Size : 25 NB to 300 NB
Flanges Used : ASTM A 105/IS 2062/SS 304/SS 316
Hydro Test : at 29.8 Kg/cm2
Spark Test : 15 KVA
Outer body : ASTM A 234 Gr WPB SCH-40/SS 304/SS 316
Lining : Teflon
Maitrik PTFE Lining is a leading supplier of Teflon Lined Pipe Fittings in Jakarta, Indonesia, offering high-quality, corrosion-resistant solutions ideal for chemical, pharmaceutical, and industrial applications.
NB | ID | RF | OD | PCD | No.Of Holes x Dia Of Holes | Lining Thickness Standard | Lining Thickness Full Vacuum | Length Max. |
| 15 | 10.80 | 34.90 | 88.9 | 60.3 | 4×15.9 | 3.0 | 3.1 | 3000 |
| 20 | 16.00 | 42.70 | 98.4 | 69.8 | 4X15.9 | 3.0 | 3.1 | 3000 |
| 25 | 20.15 | 50.80 | 108.0 | 79.4 | 4X15.9 | 3.2 | 3.5 | 3000 |
| 40 | 33.90 | 73.00 | 127.0 | 98.4 | 4X15.9 | 3.2 | 3.5 | 3000 |
| 50 | 45.50 | 92.10 | 152.4 | 120.7 | 4X19 | 3.5 | 4.6 | 3000 |
| 65 | 55.68 | 104.80 | 177.8 | 139.7 | 4×19 | 3.5 | 4.8 | 3000 |
| 80 | 70.90 | 127.00 | 190.5 | 152.4 | 4X19 | 3.5 | 5.0 | 3000 |
| 100 | 94.30 | 157.20 | 228.6 | 190.5 | 8X19 | 4.0 | 5.8 | 3000 |
| 150 | 114.10 | 215.90 | 279.5 | 241.3 | 8X22.2 | 5.0 | 6.8 | 3000 |
| 200 | 195.10 | 269.90 | 342.9 | 298.5 | 8X22.2 | 5.0 | 7.9 | 2000 |
| 250 | 247.40 | 323.90 | 406.4 | 362.0 | 12X25.4 | 5.0 | 8.8 | 2000 |
| 300 | 297.00 | 381.00 | 482.6 | 431.8 | 12X25.4 | 5.0 | 9.0 | **** |
Withstands aggressive acids, alkalis, and solvents without degrading.
Performs reliably in elevated temperature environments up to 260°C.
Ensures tight, secure connections for safe and efficient operation.
Offers durability and reduces maintenance costs in harsh industrial settings.
Yes, the Teflon lining ensures a secure, leak-proof seal, helping to minimize leakage and reduce the risk of maintenance or safety issues in industrial processes.
Standard sizes for Teflon Lined Fittings range from 25mm to 300mm, with custom sizes available upon request to fit specific application needs.
Teflon Lined Fittings are commonly used in chemical, pharmaceutical, and food industries, where corrosion resistance and contamination-free flow are essential for maintaining safety and efficiency.
Yes, Teflon Lined Fittings offer excellent resistance to a wide range of strong acids, alkalis, and solvents, making them ideal for demanding chemical environments.
We are the leading Manufacturer and Supplier of PTFE Lined Pipe, Fittings, Flanges, Spool and Valves in Indonesia,
